Sensor
|
1/2.8'', CMOS, 16:9,
Effective Pixel: 2.07MP
|
|
Scanning Mode
|
Progressive
|
|
Lens
|
10x, f＝4.7～47mm,
F1.6 ~ F3.0
|
|
Digital Zoom
|
5x
|
|
Minimal Illumination
|
0.5 Lux @ (F1.8, AGC ON)
|
|
Focus
|
Auto/Manual/ One Push
|
|
Aperture
|
Auto/Manual
|
|
Electronic Shutter
|
Auto/Manual
|
|
White Balance
|
Auto / Manual/ One Push/ 3000K/
4000K/5000K/6500K
|
|
Backlight Compensation
|
On/Off
|
|
Digital Noise Reduction
|
2D&3D Digital Noise Reduction
|
|
Video SNR
|
≥55dB
|
|
Video Adjustment
|
Brightness/ Color/ Saturation/
Contrast/ Sharpness/
BW mode/ Gamma curve
|
|
View Angle
|
6.43°(tele)--60.9°(wide)
|
|
Pan Rotation Range
|
±135°
|
|
Tilt Rotation Range
|
±30°
|
|
Pan Speed Range
|
0.1° ~ 60°/s
|
|
Tilt Speed Range
|
0.1° ~ 30°/s
|
|
Number of Preset
|
255
|
|
Preset Accuracy
|
0.1°
|
|
IPC Features
|
|
|
Video coding standard
|
H.265/H.264
|
|
Video Stream
|
First stream, Second stream
|
|
Video Format
|
HDMI:
1080P60/50/30/25/59.94/29.97;
1080I60/50/59.94;
720P60/50/30/25/59.94/29.97
Main stream:
1920x1080, 1280x720,640x480
Sub stream: 320x180,320x240,
640x360,640x480,1280x720,
1920x1080
|
|
Frame Rate
|
50Hz: 1fps ~ 25ps;
60Hz: 1fps ~ 30fps
|
|
Audio Standard
|
AAC/ MP3/ G.711A
|
|
Sampling Rate
|
16000/ 32000/ 44100/ 48000
|
|
Network Protocols
|
RTSP/RTMP, ONVIF, GBT28181
|
|
Input/Output Interface
|
|
|
Communication Interface
|
RS232 I/O: 8pin Min DIN Female;
Max Distance: 30m
|
|
Protocol
|
Pelco-D/ Pelco-P/ VISCA/ VISCA over IP
|
|
Baud Rate
|
115200/9600/4800/2400
|
|
Video Output Interface
|
HDMI, LAN, RS232 I/O, A-IN
|
|
Audio Input
|
1-ch 3.5mm audio interface,
Line In
|
|
Network interface
|
1xRJ45: 100M (10/100BASE-TX)
|
|
Power Jack
|
JEITA type (DC IN 12V),
Ethernet (PoE supported)
|
|
Generic Specifications
|
|
|
Input Voltage
|
DC 12V
|
|
Current Consumption
|
1.0A (Max)
|
|
Operating Temperature
|
20°F~80°F (-10°C~50°C)
|
|
Storage Temperature
|
20°F~95°F (-10°C~60°C)
|
|
Power Consumption
|
12W (Max)
|
|
Size
|
6”x6”x5”
(151.2mmX152.5mmX126.7mm)
|
|
Net Weight
|
3lb (1.4kg)
|
